Unlike the D series V3.0 version, which uses high-quality capacitors, power tubes, and other imported components, the V2.0 D series utilizes Chinese domestic components. This version primarily focuses on cost-effectiveness to meet various customer needs, while still retaining the features of the High Quality Nichicon capacitors,high efficiency transistors and 2 ohms stable operation.
D4-3500 FEATURE:
| ►4 x 6600W into 2ohms,4 x 6000W into 4ohms,4 x 3500W into 8ohms |
| ►Use High Quality Nichicon capacitors from Japan |
| ►High-Efficiency Transistors, Stable at 2 ohms long-term load |
| ►Active PFC,soft-switching for high adaptability |
| ►Wide voltage range of 90V-270V for harsh environments |
| ►Efficiency, energy conservation, environmental protection |
| ►Standby sleep mode，power-saving and durable |
| ►Ideal for line array,top speaker,full range speaker. For dual 18" subwoofer,it can only work stably at 4 ohms. |
| NOTE: The size is 437mm inside of the device(without the cover plate and front panel).The size is around 472mm of the complete device,but a little bit different size in the different front panel.Some series with different size that had not shown,please learn it in the parameter. Tunnel through cooling system: Cold air comes in from the front panel of the equipment, forms a duct through the radiator to take the heat away and out from the rear panel of the equipment. |
 |
