Amplifier Audio 10Q Black Capacitor 4 Channel Sound amplifier for speaker

SKU:
5 (1)
2 Sold
$683.00 $0.00
Received successfully
Coupon Code
CONTINUE SHOPPING
    Please select the information you want X
  • Ships From:
    China
    USA
    Mexico
    Germany
  • Voltage:
    110V
    220V
    Please select the information you wantX
Quantity:
  • Amplifier Audio FP10 Black Capacitor 4 Channel Sound amplifier for speaker
  • Amplifier Audio FP10 Black Capacitor 4 Channel Sound amplifier for speaker
  • Amplifier Audio FP10 Black Capacitor 4 Channel Sound amplifier for speaker
  • Amplifier Audio FP10 Black Capacitor 4 Channel Sound amplifier for speaker
  • Amplifier Audio FP10 Black Capacitor 4 Channel Sound amplifier for speaker
  • Description



 Product Description
FP6000Q
FP8000Q
FP10000Q
FP20000Q
FP22000Q
Channels
4-Channel Power Amplifier
Class
Class TD Power Amplifier
8Ω Stereo Power (RMS)
625WX4
1000WX4
1350WX4
2200WX4
2500WX4
4Ω Stereo Power (RMS)
1300WX4
1600WX4
2100WX4
4000WX4
4650WX4
8Ω Bridged Power(RMS)
2500WX2
3200WX2
4200WX2
8000WX2
9300WX2
4Ω Bridged Power(RMS)
3000WX2
3800WX2
5000WX2
9000WX2
15000WX2

FP7000
FP9000
FP14000
FP24000
Channel
2 Channel Power Amplifier
Class
Class TD Power Amplifier
8Ω Stereo Power (RMS)
1500WX2
1800WX2
2400WX2
4200WX2
4Ω Stereo Power (RMS)
2800WX2
3000WX2
4400WX2
7500WX2
8Ω Bridged Power (RMS)
5600W
6000W
8800W
/
4Ω Bridged Power (RMS)
7000W
9000W
14000W
/

  • DS-10Q amplifier performance description

-4 Channel Class TD Switching power audio amplifier.
-4* 2100 Watts into 4Ohms, 4* 1350 Watts into 8Ohms.
-Create SUPER sound quality.
-Good for single15"/dual15" speaker.
-Separately controllable on Gain.
-Scalable Voltage Peak Limiter (VPL).
-Bridge-mode operation for Touring Applications.
-Comprehensive protection scheme.
-Extended heatsink to 69 mm.
-Use high-quality capacitor 3300uf 200V.
-High-quality speakon connectors.
-High-quality fans from TAIWAN.




Must know before buying:
Full-range speaker [line array speaker, professional speaker]: the power of the power amplifier should be greater than 1.5 times or more;
Subwoofer speaker: The power of the amplifier should be more than 2 times or more, because the current of the low frequency speaker is larger than that of the full frequency speaker!
